Available with Binocular viewing head with 45° viewing angle, or Trinocular viewing head with 45° viewing angle
1.0x glass lens shield
Trinocular with fixed 50:50 light split, eyepieces:camera port
Widefield 10x/22mm focusing eyepieces
0.67x – 4.5x zoom magnification range
6.7:1 Zoom ratio
Magnification range 6.7x-45x (with 10x eyepieces), with click stops at 0.67, 0.8, 1, 1.2, 1.5, 2, 2.5, 3, 3.5, 4 and 4.5; with adjustable zoom range limits
Interpupillary Distance Adjustment 52mm – 76mm
Field of view 32.8mm - 4.8mm (1x or no auxiliary lens)
110mm working distance (1x or no auxiliary lens)
Plain Focusing Stand, with tension adjustment, 4” (100mm) of continuously smooth focus travel
125mm black and white stage plate
Airtight and anti-mold design
Note: Excelis™ HDS and Excelis HDS Lite cameras are not recommended for use with the Z850 series microscopes
Shipping weight 14lbs. with Binocular head, 15lbs. with Trinocular head
